Name: PDLC 4F SM SX Fiber Optic Patch Cables LSZH 48mm Length With 50M 100M
Brand: HICORPWELL
Price: 1 USD

Brand Name : HICORPWELL

Model Number : PDLC 2F 4F SX SM Waterproof Patch Cables

Certification : IEC 60794-2-10/11

Place of Origin : China

MOQ : 10sets

Price : negotiation

Payment Terms : Western Union, L/C, T/T

Supply Ability : 5000pcs Per Week

Packaging Details : Max 100m/ per reel for IP67LC/LC 1m with FullAXS housing at both ends Fiber Optic Patch Cables

Cable Type : PDLC 2F 4F SX SM Waterproof Armoured Patch Cables

Connectors : PDLC with LC UPC

Length : 50M

Cable : 4.8MM

Reel : Without reel be together

Application : Outdoor Communication

Contact Now

With the continuous development of optical fiber communication technology, 4G commercial trial

network, high-speed local area networks and optical access network such as the market that is a

sustained manner.PDLC fiber optic cable connector assemblies are rapidly becoming the standard

connector interface.

This patch cord uses standard size of Duplex LC Connectors,and the outer housing is metal protective

PDLC device.

These patch cords meet with the functions of waterproof, dustproof and are widely used in FTTA,

Base station, and the outdoor waterproof condition.

Connector	End A	Compact RRH/BBU Cover Connector
	End B	PDLC (duplex LC),or SC,FC,ST,MPO,MTP......
Fiber Core		2,4…12
Mode		Singlemode			Multimode
Operating Wavelength(nm)		1310/1550			850/1310
Polishment		UPC	APC		UPC
Insertion Loss(Max.dB)		0.2			0.3
Return Loss(Min.dB)		55		60	35
Mating times		500 Min
Durability(Max.dB)		0.2
Reaptability(Max.dB)		0.5
Operating Temperature(℃)		-40~+85
Storage Temperature(℃)		-40~+85

PDLC 4F SM SX Fiber Optic Patch Cables LSZH 4.8mm Length With 50M 100M
