FTTH Flat Drop Optical Fiber Cable Patch Cord With SC / APC / UPC Connector
♦ FTTH Drop Cable Characteristics
Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property of drop cable
Two parallel strength members ensure good performance of crush resistance to protect the fiber;
Novel flute design, easily strip and slice,simplify the installation and maintenance ftth drop cable
Low smoke, zero halogen ftth drop cable and flame retardant sheath;
Factory Price Drop Cable FTTH Flat Drop Optical Fiber Cable Patch Cord with SC/APC/UPC Connector
Steel wire as the additional strength member ensures good performance of ftth drop cable tensile strength.
| FTTH Drop Cable Structure | Unit | Parameter |
| FTTH Drop Cable Fiber count | Fibers | 2(G657A1) |
| Stainless Steel tube | nm | Nom. Ø2.1/1.5 |
| FTTH Drop Cable Cable Diameter | nm | Ø6.0±0.1 |
| FTTH Drop Cable Tensile strength | Long term | N | 600 |
| Short term | N | 800 |
| FTTH Drop Cable Tensile strength | Long term | N | 2000 |
| Short term | N | 3000 |
| Crush Resistance | Dynamic | nm | ≥120 |
| Crush Resistance | Static | nm | ≥60 |
| Drop Cable Operating Temperature | ℃ | -20 ℃--- +85℃ |
Factory Price Drop Cable FTTH Flat Drop Optical Fiber Cable Patch Cord with SC/APC/UPC Connector
.Applications :
1.Communication Workshop
2.FTTH
3.Local Area Network
4.Fiber Sensor
5.CATV
6.Fiber Optical Communication System
Performance index:
| Parameter | Unit | FC, SC, LC,ST fiber optic patch cord | ST, MU | MT-RJ, MPO | E2000 |
| SM | MM | SM | MM | SM | MM | SM |
| PC | UPC | APC | PC | PC | UPC | PC | PC | UPC | PC | PC | APC |
| Insertion loss(typical) | dB | ≤ 0.3 | ≤ 0.2 | ≤ 0.3 | ≤ 0.2 | ≤ 0.3 | ≤ 0.2 | ≤ 0.2 | ≤ 0.3 | ≤ 0.2 | ≤ 0.2 | ≤ 0.3 | ≤ 0.3 |
| Return loss | dB | ≥ 45 | ≥ 50 | ≥ 60 | ≥ 30 | ≥ 45 | ≥ 50 | ≥ 30 | ≥ 45 | ≥ 50 | ≥ 35 | ≥ 55 | ≥ 75 |
| Operating wavelength | nm | 1310, 1510 | 1310, 1510 | 1310, 1510 | 1310, 1510 |
| Exchangeability | dB | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 |
| Vibration | dB | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 | ≤ 0.2 |
| Operating temperature | | -40~75 | -40~75 | -40~75 | -40~75 |
| Storage temperature | | -45~85 | -45~85 | -45~85 | -45~85 |
| Cable diameter | mm | 3.0, 2.0, 0.9 | 3.0, 2.0, 0.9 | 3.0, 2.0, 0.9 | 3.0, 2.0, 0.9 |
5.Availabilities:
1.Full specifications, FC, SC, ST, LC, MTRJ, E2000, etc.
2.Simplex and Duplex assemblies available
3.Singlemode and multimode available
4.PC, UPC and APC polishing available
5.PVC and LSZH outer sheath.
6.0.9mm, 2.0mm and 3.0mm cable size.
7.Hybrid patch cords are available upon request
8.Pigtail available
9.Loopback available
10.Customized length
